Scell-it
EAK
eakecrou-crante-alu-tete-fraisee-90
blind rivet nut - alu - countersunk head 90°
Dimensions
Technical data
| Diameter | length | G | K | Shear | ØDrill | Tensile | Référence | |
|---|---|---|---|---|---|---|---|---|
| Diamètre | Ø perçage mm |
|||||||
| M4 | 11,5 | 1.5-3.5 | 9.0 | 1000 | 6.0 | 2800 | EAK0435 | |
|
Diameter : M4 length : 11,5 G : 1.5-3.5 K : 9.0 Shear : 1000 ØDrill : 6.0 Tensile : 2800 |
||||||||
| M5 | 13,5 | 1.5-4.0 | 5.0 | 1100 | 7.0 | 4900 | EAK0540 | |
|
Diameter : M5 length : 13,5 G : 1.5-4.0 K : 5.0 Shear : 1100 ØDrill : 7.0 Tensile : 4900 |
||||||||
| M6 | 16,0 | 1.5-4.5 | 12.0 | 2200 | 9.0 | 9200 | EAK0645 | |
|
Diameter : M6 length : 16,0 G : 1.5-4.5 K : 12.0 Shear : 2200 ØDrill : 9.0 Tensile : 9200 |
||||||||
| M8 | 19,0 | 1.5-4.5 | 14.0 | 2400 | 11.0 | 14000 | EAK0845 | |
|
Diameter : M8 length : 19,0 G : 1.5-4.5 K : 14.0 Shear : 2400 ØDrill : 11.0 Tensile : 14000 |
||||||||
| M10 | 21,0 | 1.5-4.5 | 15.0 | 3800 | 13.0 | 21000 | EAK1045 | |
|
Diameter : M10 length : 21,0 G : 1.5-4.5 K : 15.0 Shear : 3800 ØDrill : 13.0 Tensile : 21000 |
||||||||
