slotted multi grip nut - zinc plated steel - flanged head

Download PDF file

Dimensions

Technical data

Diameter length ØDrill Shear Tensile G Référence
Diamètre Ø perçage
mm
M5 22 7.48-7.62 2300 10000 0.5-4.45 UCD05045
Diameter : M5
length : 22
ØDrill : 7.48-7.62
Shear : 2300
Tensile : 10000
G : 0.5-4.45
M6 8.80-8.93 3000 20000 0.5-7.10 UCD06070
Diameter : M6
length :
ØDrill : 8.80-8.93
Shear : 3000
Tensile : 20000
G : 0.5-7.10
M8 11.11-11.5 4000 26000 0.5-7.10 UCD08070
Diameter : M8
length :
ØDrill : 11.11-11.5
Shear : 4000
Tensile : 26000
G : 0.5-7.10
